A Virtual Private Network (VPN) is a technology that creates a secure and encrypted connection over a less secure network, such as the internet. It allows users to send and receive data across shared or public networks as if their computing devices were directly connected to a private network. This provides privacy, anonymity, and security for users by masking their IP addresses and encrypting all transmitted data.
Typical VPN Log Parameters
- User ID: Identifies the user accessing the VPN.
- Timestamp: Records the date and time of each session.
- Source IP: The IP address from which the connection originated.
- Destination IP: The server or service the VPN connects to.
- Duration: How long the connection lasted.
- Data Transferred: Amount of data sent and received during the session.
- Session Start/End Time: When the VPN connection started and ended.
- VPN Gateway: The VPN server used for the connection.
- Authentication Status: Success or failure of the VPN connection attempt.
- Encryption Method: Details about the encryption protocol used.
- Device Type/ID: Information about the device used for the connection.
SOC Use Cases for VPN Logs
Unauthorized Access Detection
- Objective: Identify and respond to unauthorized VPN access attempts.
- Method: Monitor failed authentication attempts and repeated login failures from the same source IP or user ID. Alert on suspicious access patterns such as logins at unusual hours or from geographically improbable locations.
- MITRE: T1110 (Brute Force), T1078 (Valid Accounts), T1098 (Account Manipulation), T1199: Trusted Relationship
Abnormal Usage Monitoring
- Objective: Detect unusual activity that could indicate a security breach or misuse.
- Method: Analyze data volumes and session durations against typical user profiles. Significant deviations could trigger an investigation.
- MITRE: T1078 (Valid Accounts), T1497 (Virtualization/Sandbox Evasion), T1482 (Domain Trust Discovery)
Secure Configuration Compliance
- Objective: Ensure that VPN connections comply with security policies.
- Method: Check encryption protocols and VPN gateways used for connections against the organization’s security standards. Non-compliance can be flagged for immediate review.
- MITRE: T1556.005 (Exploitation for Credential Access), T1556.003 (Modify Authentication Process), T1599 (Network Boundary Bridging)
Geolocation Analysis
- Objective: Monitor connections from high-risk locations or geographically inconsistent access points.
- Method: Integrate geolocation data for each VPN login attempt to identify connections from restricted or anomalous locations, possibly indicating compromised credentials.
- MITRE: T1078 (Valid Accounts), T1596 (Search Closed Sources)
Bandwidth and Resource Usage
- Objective: Optimize network performance and prevent misuse of resources.
- Method: Monitor and report on high bandwidth usage, potentially prioritizing or restricting bandwidth on a per-session basis based on business needs and policies.
- MITRE: T1498 (Network Denial of Service), T1499 (Endpoint Denial of Service)
VPN Access Trends and Reporting
- Objective: Provide insights into remote workforce behavior and network usage patterns.
- Method: Generate regular reports on VPN usage, including peak times, most used gateways, and total data transferred, to aid in capacity planning and operational adjustments.
- MITRE: T1046 (Network Service Scanning), T1033 (System Network Configuration Discovery), T1049 (System Network Connections Discovery)
Insider Threat Detection
- Objective: Identify potential insider threats through abnormal VPN access or activities.
- Method: Alert on unusual activities like accessing sensitive resources through VPN beyond normal working hours or from multiple devices simultaneously.
